Automatic Tire Linear Polyurethane Pouring Machine HY-TP3I1-120A/250A
機械部件
PRODUCT GENERALIZATIONS
技術參數
TECHNICAL PARAMETER
| Model | HY-TP3I1-120A/250 |
| Max. travel speed | AX,Y=60m/min |
| Work area | X,Y=380.600.100 |
| Raw Material Quantity | 4 |
| Tank Volume | 120/250 |
| L/R Output of Flow Control Pump | 20 |
| Flow Control pump Quantity | 4 |
| Ratation Speed of Flow Control Pump(r/min) | 60-280 |
| Measuring precision | 0.5 |
| R/MIN Ratation Speed of Pouring Head Mixer | 9400 |
| Cleaning Type of Pouring Head | 自動Automatic |
| Total Times of Continuous | >80 |
| Pouring During Pouring Head Cleaning Period (times) | 130 |
| Max. output Volume | 60/80 |
| Work digits | 三色三密度Three Density Three Colors |
| Characteristic of Product Electrical supply | 400V 30-45A/50HZ(60Hz) |
| Total Power | 30KW |
